Size Chart
Pathlite:ON 5 SUV step-through - Frame Geometry
| Frame Size | Body Height (cm) | Seat Height (mm) | Seat Tube Length (mm) | Top Tube Length (mm) | Head Tube Length (mm) | Head Tube Angle (°) | Seat Tube Angle (°) | Chainstay Length (mm) | Wheel Base (mm) | Stack (mm) | Reach (mm) | Stand-over Height (mm) | Bottom Bracket Offset (mm) | Spacer (mm) | Crank Length (mm) | Maximum Seat Post Insertion Depth (mm) | Minimum Seat Post Insertion Depth (mm) | Wheel Size (") | Disc Size (mm) | Rim height (mm) | Battery capacity (Wh) | Stem Length (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| S | ≤ 170 | 583 - 733 | 385 | 565 | 111 | 68.5 | 73.5 | 460 | 1.103 | 625 | 380 | 450 | 65 | 10 | 170 | 250 | 100 | 27.5 | 180 / 180 | 21 | 500 | 65 |
| L | ≥ 180 | 673 - 823 | 475 | 625 | 164 | 68.5 | 73.5 | 460 | 1.168 | 675 | 425 | 450 | 65 | 10 | 170 | 250 | 100 | 27.5 | 180 / 180 | 21 | 500 | 65 |
